Double Swing Gate
Aluminum Driveway Gate Kit, Double Swing Gate – Los Angeles Style
5
(1)
Reviews
Build a Los Angeles Style aluminum driveway gate with this DIY double swing gate kit. Its open pattern uses 5.5-inch horizontal aluminum slats and 1/2-inch spacers. Choose a 7′, 9′, 11′ or 13′ width, a 4′, 5′ or 6′ height, and one of six finishes. The kit includes components for two gate leaves: aluminum frames and slats, side posts, hinges, a keyed lever and a cane bolt. Assembly and installation are required.
Estimated delivery: 2–8 business days for every available finish. Shipping within the United States, excluding Hawaii.
STARTING AT $2,332.32
WHAT’S INCLUDED:
Los Angeles Style aluminum driveway gate kit
Build a two-leaf aluminum driveway gate with an open horizontal rhythm with broad 5.5-inch slats and half-inch spacers. This cut-to-fit double swing gate kit is supplied as components for on-site assembly. Select the complete gate width, height and finish above to see the current configuration and price.
Why choose the Los Angeles design?
Choose this pattern when you want broad horizontal lines with deliberate gaps between slats. The half-inch aluminum spacers create the repeated open pattern. Confirm the final spacing and cut plan for both leaves before assembly. See the product images for the style and finish; the final appearance depends on the selected size, color and installation.
What comes with both gate leaves?
- Gate structure: two aluminum side posts, four aluminum gate-frame profiles, four matching slide-on frame covers, two post covers and one gate-frame stopper. Supplied profile stock lengths follow the selected gate height.
- Top and end pieces: four side-post caps and eight gate-frame caps.
- Operating hardware: four 4-inch adjustable self-closing hinges, one Schlage keyed entry lever and one 12-inch heavy-duty cane bolt.
- Assembly fasteners: two packs of 100 #8 × 1/2-inch stainless-steel pan-head self-drilling screws.
- Los Angeles infill: 5.5-inch slats: 16, 20 or 24 for the 4-, 5- or 6-foot heights; two 25-piece spacer packs at each height. These quantities cover the complete two-leaf kit; final cut lengths depend on the selected size and installation.
Slats and Spacers for Each Size
These quantities cover both gate leaves. Supplied slat lengths are shown below; the post, frame, cover and stopper lengths match the selected gate height.
| Size (width × height) | 1-inch slats | 5.5-inch slats | 1/2-inch spacers |
|---|---|---|---|
| 7’W X 4’H | None | 16 × 3′ | 2 packs of 25 (50 spacers) |
| 7’W X 5’H | None | 20 × 3′ | 2 packs of 25 (50 spacers) |
| 7’W X 6’H | None | 24 × 3′ | 2 packs of 25 (50 spacers) |
| 9’W X 4’H | None | 16 × 4′ | 2 packs of 25 (50 spacers) |
| 9’W X 5’H | None | 20 × 4′ | 2 packs of 25 (50 spacers) |
| 9’W X 6’H | None | 24 × 4′ | 2 packs of 25 (50 spacers) |
| 11’W X 4’H | None | 16 × 5′ | 2 packs of 25 (50 spacers) |
| 11’W X 5’H | None | 20 × 5′ | 2 packs of 25 (50 spacers) |
| 11’W X 6’H | None | 24 × 5′ | 2 packs of 25 (50 spacers) |
| 13’W X 4’H | None | 16 × 6′ | 2 packs of 25 (50 spacers) |
| 13’W X 5’H | None | 20 × 6′ | 2 packs of 25 (50 spacers) |
| 13’W X 6’H | None | 24 × 6′ | 2 packs of 25 (50 spacers) |
Find Your Exact Kit Contents
Choose your size and color below to open that variation, then expand “View all included items and packing list” beside the price. Each list identifies every item, quantity, supplied length and finish for the complete two-leaf kit. Share the exact variation link when preparing an order.
Finish guide: Black, Bronze, White, Dark Grey and Light Gray kits include matching aluminum posts, frames, covers, stopper, caps, spacers where required, and slats. Wood kits include wood-look aluminum slats with Black posts, frames, covers, stopper, caps and spacers where required. Hinges, assembly screws, keyed entry lever and cane bolt are Black for every finish.
| Size (width × height) | Black | Bronze | White | Dark Grey | Light Gray | Wood |
|---|---|---|---|---|---|---|
| 7’W X 4’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 7’W X 5’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 7’W X 6’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 9’W X 4’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 9’W X 5’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 9’W X 6’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 11’W X 4’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 11’W X 5’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 11’W X 6’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 13’W X 4’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 13’W X 5’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
| 13’W X 6’H | Black | Bronze | White | Dark Grey | Light Gray | Wood |
Choose the right driveway gate size
Available complete-gate width options are 7′, 9′, 11′ and 13′; heights are 4′, 5′ and 6′. The width selection describes the two-leaf gate option, not the width of each leaf. Measure the finished opening, confirm post placement and swing clearance, and select a size that suits your installation. The aluminum slats are supplied as stock lengths of 3′, 4′, 5′ or 6′ for the 7′, 9′, 11′ or 13′ width options respectively. These are not final cut dimensions. Use the Technical Specifications tab for the full size and component schedule.
Finish, assembly and what to plan separately
Choose Black, Bronze, White, Dark Grey, Light Gray or Wood in the selector above. Wood is a wood-look finish on aluminum. The gate arrives as components; cutting, assembly and installation are required. The supplied single-leaf installation illustrations show shared assembly steps, but a double swing gate needs a separate plan for both leaves and their center meeting point. Confirm mounting, clearances, final cuts and local requirements before drilling or cutting. Site-specific supports, concrete, electrical work, a gate operator and installation labor are not listed in the supplied kit schedule; plan those separately if your project needs them.
Shipping and delivery
Estimated delivery: 2–8 business days for every available finish, including Wood. Shipping is available within the United States, excluding Hawaii. Delivery timing is an estimate; choose the color and size above for the live product price.
Ready to compare? Select your size and finish above, review the Technical Specifications and Q&A tabs, and add the Los Angeles Style aluminum driveway gate kit to your cart when the fit is confirmed. For unusual openings or operator plans, contact Alumission before ordering.
Box Weight
Packed weight varies by selected size. Contact Alumission for the exact weight of your kit.
Box Dimension
Request the exact package count and dimensions for your selected gate size before arranging delivery.
TECHNICAL SPECIFICATIONS & INSTALLATION
Los Angeles aluminum driveway gate: design and construction
This DIY kit assembles into a two-leaf, double swing aluminum driveway gate with evenly spaced broad horizontal slats. Choose the catalog width, height and finish above to see the price for your configuration. The kit is supplied as components for field assembly and fitting.
Technical specifications
| Gate configuration | Two swing leaves for a residential driveway entrance. |
|---|---|
| Catalog size options | 7′, 9′, 11′ or 13′ wide; 4′, 5′ or 6′ high. Confirm the opening and post positions before cutting. |
| Frame profile | Four Aluminum Gate Frame profiles, with 5.000″ × 1.750″ nominal cross-section, 1.402″ lock-side section and an integrated slat-fastening channel. The matching slide-on covers conceal compatible assembly screws. |
| Side posts | Two Aluminum Side Posts, each with a 1.750″ × 2.115″ nominal cross-section and 0.826″ channel opening. Post length in the supplied schedule follows the chosen 4′, 5′ or 6′ gate height. |
| Frame and post material | 6063-T6 aluminum profiles with an exterior powder-coated finish, as specified on the linked component pages. |
| Infill | 5.5-inch horizontal aluminum slats with 1/2-inch spacers. Slat length depends on the selected width, while the supplied schedules vary slat count by height. Confirm the cut plan for both swing leaves before cutting; the single-leaf illustrations below are only a component assembly reference. |
| Gate hardware | Four 4-inch adjustable self-closing hinges, one Schlage keyed entry lever, one 12-inch heavy-duty cane bolt and one gate-frame stopper. |
| Assembly parts | Four gate-frame slide-on covers, two post covers, four side-post caps, eight gate-frame caps and two packs of 100 #8 × 1/2-inch stainless-steel pan-head self-drilling screws. Spacer packs vary by style and height. |
| Finishes | Black, Bronze, White, Dark Grey, Light Gray and Wood options are listed in the selector above. |
Size note: The catalog width is the selected two-leaf gate option; the component stock lengths and final field cuts are separate measurements. Measure the installed opening and confirm a double-swing cutting plan for each leaf before cutting any aluminum.
Stock lengths by selected gate size
The size chart below shows the aluminum slat lengths supplied with each complete double swing driveway gate kit. The catalog width describes the complete two-leaf gate; the slat stock length is a supplied component length, not a finished cut dimension.
| Catalog gate width | Aluminum slat stock length |
|---|---|
| 7′ | 3′ |
| 9′ | 4′ |
| 11′ | 5′ |
| 13′ | 6′ |
Two side posts, four gate-frame profiles, four slide-on frame covers, two post covers and one gate-frame stopper use the selected 4′, 5′ or 6′ height as their stock length. Confirm final cuts and clearances for both leaves before assembly.
Los Angeles Style slat schedule by gate height
These slat and spacer quantities cover both gate leaves at every offered width: 7′, 9′, 11′ and 13′. Quantities vary by height; the slat stock length varies by width as shown above. Confirm final cut dimensions before assembly.
| Gate height | 5.5-inch aluminum slats | 1/2-inch spacer packs (25 per pack) |
|---|---|---|
| 4′ | 16 | 2 |
| 5′ | 20 | 2 |
| 6′ | 24 | 2 |
Before assembly
- Confirm the finished opening, gate height, swing clearance and support structure.
- Select the finish and size above, then review the parts list and the single-leaf component reference below.
- Lay out both leaves, side posts, hinge positions, keyed lever and cane bolt before cutting or drilling.
- Confirm the double-swing cut list and fastener placement for both leaves. Verify local mounting and clearance requirements for the completed gate.
Common questions about this driveway gate kit
Does the kit arrive as an assembled gate?
No. This DIY aluminum driveway gate kit is supplied as components for two swing leaves. Assembly and fitting take place on site using a double-swing cut plan; the single-leaf component reference below can help with shared assembly steps. Installation labor is not included.
What gate hardware is supplied?
The parts schedule lists four adjustable self-closing hinges, a Schlage keyed entry lever, a heavy-duty cane bolt, a gate-frame stopper and stainless-steel assembly screws. See Product Details for the complete kit list.
How do I choose a size?
Measure the finished driveway opening and confirm post positions, swing clearance and the height you need. Select the matching width, height and finish above, then confirm the cut lengths for both leaves before cutting the aluminum components.
What are the frame and side posts made of?
The linked gate-frame and side-post specifications identify 6063-T6 aluminum with an exterior powder-coated finish. Choose the available color or wood-look option in the selector above.
Single-Leaf Assembly Reference for Double Swing Kits
These four pages illustrate assembly of one swing leaf and its side posts. A double swing driveway gate has two leaves with a center meeting point, cane bolt and latch details that are not covered by these illustrations. Use them as a reference for shared components only. Do not apply the illustrated single-leaf slat cut rule to the full driveway opening. Confirm the cut dimensions for both leaves before cutting. Click a page to view it at full size.
Los Angeles Double Swing Gate Questions & Answers
Plan your driveway entrance with clear answers about the style, fit, kit contents, installation and everyday care.
Style & Finishes
What makes the Los Angeles double swing gate different?
Los Angeles uses evenly spaced 5.5-inch horizontal slats with 1/2-inch spacers for a broad, repeated horizontal pattern.
How does Los Angeles compare with the other gate styles?
Choose Los Angeles for consistent broad slats with visible gaps. New York uses close-set broad slats; Dallas and Miami add narrow accent slats; San Francisco uses 1-inch slats.
How much privacy does Los Angeles Style provide?
The half-inch spaces between the broad slats allow sightlines through the gate. Choose this style for an open horizontal look rather than a completely closed screen.
Which finishes can I choose, and is Wood real timber?
The selector lists Black, Bronze, White, Dark Grey, Light Gray and Wood. Wood is a decorative wood-look finish on aluminum, not timber. Compare the product photos before selecting a finish, and confirm your chosen size and color for the current price.
Kit & Installation
Does the kit arrive assembled, and what is included?
It arrives as components for two gate leaves, requiring cutting, assembly and installation. The schedule lists aluminum frames, slats and side posts, matching covers and caps, four adjustable self-closing hinges, a Schlage keyed entry lever, a cane bolt, a stopper and assembly screws. Slat and spacer quantities vary by style and height; use Product Details for the complete schedule.
Are support foundations, a motor and installation included?
Site-specific supports, concrete, electrical work, a gate operator and installation labor are not listed in the kit schedule. Plan these separately where needed. The included aluminum side-post profiles do not replace checking that the supporting structure and anchors are suitable for the complete installation.
Can I assemble this kit myself, and what tools will I need?
The kit is intended for field assembly by someone comfortable measuring, cutting aluminum, drilling and fitting gate hardware. Plan for a tape measure, level, drill, suitable bits and a miter saw with an aluminum-cutting blade; mounting tools depend on the support material. Get installation help if you are unsure about anchoring, alignment or handling the gate leaves.
Can I use the single-leaf guide to cut this double gate?
Use the illustrated guide in Technical Specifications only as a reference for shared components. A double swing gate needs a separate cut plan for both leaves and their center meeting point. Do not apply a single-leaf opening-minus-8-inch rule to the full driveway opening. Confirm both leaf dimensions before cutting.
Sizing & Planning
Does the listed width cover both gate leaves?
Yes. The 7′, 9′, 11′ and 13′ selections describe the complete two-leaf gate option, not each leaf. The available heights are 4′, 5′ and 6′. Supplied stock lengths are not final cut dimensions; confirm the installed opening and the cut plan for both leaves before ordering or cutting.
How do I measure for a double swing driveway gate?
Measure the finished opening at several heights, record the support positions and ground levels, and check the full opening path of each leaf. Allow for the specified hinges, center meeting gap, latch and ground clearance. Send Alumission your measurements and photos if the correct kit size or mounting arrangement is unclear.
How much room do the two leaves need to swing?
Each leaf needs a clear arc from its hinge to the required open position. Check parked cars, walls, landscaping and changes in driveway level throughout that arc. Two shorter leaves can need less depth than one full-width leaf, but the exact space depends on the finished leaf widths, hinge positions and opening angle.
Can this gate work on a sloped driveway?
Check the ground under the entire swing path, not just where the gate closes. Rising ground can stop a leaf from opening. Have the slope and mounting layout reviewed before ordering; a different gate arrangement may suit the site better. Do not assume extra ground clearance alone will solve every slope.
Automation & Care
Can I add an automatic double swing gate opener?
Discuss automation with Alumission and a qualified gate installer before buying an operator. Compatibility depends on each leaf’s finished size and weight, the slat pattern, wind exposure, supports and operator mounting. The kit does not include a motor. The installer must also plan the required safety devices and access controls for the complete system.
How do the keyed lever and cane bolt work together?
The keyed lever controls the latching point, while the cane bolt secures one leaf in its closed position as planned in the installation. Confirm which leaf is used most often and how both leaves meet before drilling. For an automated gate, have the installer specify a compatible locking and stopping arrangement.
How should I clean and maintain the aluminum gate?
Wash the aluminum with mild soap, water and a soft cloth, then rinse. Avoid abrasive pads and harsh chemicals that can damage the finish. Periodically check the hinges, latch, cane bolt and fasteners for alignment or looseness, and follow the hardware maker’s maintenance instructions. Keep the swing path clear.
What should I check before placing my order?
Confirm the style, finish, total width, height, support structure, slope, swing clearance and any automation plans. Check local permit or HOA requirements for your property. Select the size and finish for the current price, and review delivery information and the return policy before ordering. For help, contact Alumission with photos and measurements.
