Aluminum Post 2 Channels
Price range: $93.90 through $146.48
BUILT FOR MODERN ALUMINUM FENCE & GATE SYSTEMS
One Aluminum Profile. Three Installation Uses.
The Alumission Aluminum Post – 2 Channels is a versatile, American-made profile designed for horizontal fence slats, vertical-slat fence construction, and Alumission sliding gate frames. Two full-length slat channels and concealed screw tracks create a strong, clean installation with no exposed fasteners after the optional snap covers are installed.
Choose your required length and powder-coated color above.
In-Line Fence Post
Install the profile vertically in a properly sized concrete footing to create an in-line post for a straight fence run. Horizontal aluminum slats slide into both opposing channels and are secured through the dedicated screw tracks.
Top & Bottom Rails
Install the profile horizontally as the top and bottom frame for a vertical-slat aluminum fence. The channels capture and align the slats while creating a clean framed appearance.
Sliding Gate Frame
Use the profile as part of the Alumission aluminum sliding gate system. Its multi-chamber construction forms the gate frame and holds the selected aluminum infill slats.
Clean, Concealed-Fastener Installation
Each side of the profile includes a dedicated narrow screw track. After the slats are positioned inside the main channels, use compatible #6 or #8 screws to fasten the slats securely to the aluminum profile.
Press the matching Snap Cover for Post 2 Channels into the tracks to conceal the screws and create a smooth, professional finish.
SOLD SEPARATELY
- Snap Cover for Post 2 Channels
- Compatible #6 or #8 screws
Product Highlights
- Three-in-one profile for fence posts, vertical-slat rails, and sliding gate frames
- Two opposing channels for inserting aluminum slats
- Dedicated tracks for #6 or #8 attachment screws
- Compatible with concealed Snap Covers
- Powder coated, corrosion-resistant, and made in the USA
- Available in Black, Bronze, White, Dark Gray, and Light Gray
How the Slat System Works
- Position the post or frame profile.
- Slide and align the aluminum slats inside the channels.
- Secure the slats through the screw tracks using compatible #6 or #8 screws.
- Press the matching Snap Covers into place to conceal the hardware.
What Is Included
- One Aluminum Post – 2 Channels in the selected length and color
Sold Separately
- Snap Cover for Post 2 Channels
- Compatible #6 or #8 screws
- Aluminum fence or gate slats
- Concrete and installation materials
- Sliding gate assembly hardware, when used for a gate frame
Important Installation Information
When installing the profile vertically as an in-ground post, place it in a properly sized concrete footing and keep it level and plumb while the concrete cures. Required footing dimensions, post embedment, post spacing, screw selection, and reinforcement depend on fence height, soil conditions, wind exposure, gate size, and applicable building requirements. Verify the requirements for your project before installation.
Build a Cleaner Aluminum Fence or Sliding Gate
Use this profile to create straight horizontal fence runs, framed vertical-slat fencing, or an Alumission aluminum sliding gate. Select your preferred length and powder-coated color, then add the matching Snap Covers and attachment screws required for your installation.
TECHNICAL SPECIFICATIONS
Aluminum Post – 2 Channels
Key profile measurements and material information from the engineering drawing.
| Specification | Measurement |
|---|---|
| Overall profile cross-section | 3.500″ × 1.752″ |
| Center hollow cavity | Approx. 1.299″ × 1.299″ |
| Slat channel clear opening | 0.827″ |
| Approximate slat insertion depth | 1″ |
| Nominal unmarked wall thickness | 0.057″ |
| Profile cross-sectional area | 0.902 sq. in. |
| Approximate profile weight | 1.083 lb./linear ft. |
| Aluminum alloy | 6063-T6 |
| Profile type | Hollow aluminum extrusion |
| Finish | Powder coated |
| Installation orientation | Vertical or horizontal |
Measurement note: All dimensions are nominal. Standard aluminum extrusion tolerances apply.
Questions & Answers
Find answers about applications, dimensions, compatible components, installation, finishes, ordering, and care for the Aluminum Post – 2 Channels.
Product & Applications
What is the Aluminum Post – 2 Channels?
It is a powder-coated 6063-T6 aluminum extrusion with two opposing channels designed to receive aluminum slats. It can be installed vertically or horizontally in Alumission fence and sliding gate systems.
What is this aluminum post used for?
This profile has three primary uses: an in-line post for horizontal-slat fencing, a top and bottom rail for vertical-slat fencing, and a frame profile for Alumission aluminum sliding gates.
Can this post be installed directly into the ground?
The post is designed to be embedded in a properly sized concrete footing. The concrete surrounds the embedded portion of the post and holds it level and plumb.
Can it be used as a surface-mounted post?
It may be used with a compatible post-base assembly where the project design allows. Surface-mount suitability depends on fence height, wind exposure, mounting surface, fasteners, and applicable building requirements.
Can the profile be installed horizontally?
Yes. It can be installed horizontally as the top and bottom frame for a vertical-slat aluminum fence. The channels hold and align the vertical slats.
Can it be used to build a sliding gate?
Yes. This profile is used as part of the Alumission aluminum sliding gate system to create the outer gate frame and hold the selected aluminum slats.
Is this an end post or an in-line post?
It is primarily an in-line post because the two main slat channels face opposite directions. For an end, side, or corner location, use the Alumission profile designed for that specific position.
Can this profile be used as a structural building column?
No. It is intended for Alumission fence and gate systems. It should not be used as a structural column for a building, patio cover, balcony, or other load-bearing structure.
Can it be used with glass panels?
Yes. Use the profile with the Aluminum Post Cover for Glass and the 1″ Aluminum Slat for Glass. This creates a channel for compatible 1/4″-thick materials, including glass, acrylic, aluminum sheet, and similar panel materials.
Slats, Screws & Covers
How are the aluminum slats installed?
Slide the slats into the main channels, align them in the required positions, and secure them through the narrow screw tracks on the sides of the profile.
What screws should be used to attach the slats?
The dedicated screw tracks are designed for compatible #6 or #8 screws. The proper screw type and length depend on the selected slat and installation conditions.
Are the attachment screws included?
No. The #6 or #8 attachment screws are sold separately.
Is the Snap Cover for Post 2 Channels included?
No. The matching Snap Cover for Post 2 Channels is sold separately.
What is the snap cover used for?
The snap cover presses into the narrow screw track after the slats and screws are installed. It conceals the fasteners and creates a clean, finished appearance.
How many snap covers do I need?
Each post requires two Snap Covers, with each cover matching the full length of the post.
Is a post cap included?
No. The product includes one aluminum profile in the selected length and color. Post caps, bases, covers, screws, slats, and installation materials are sold separately.
Which cap fits this post?
The compatible accessory is the In-line Post Cap – Two Channel Post Cap, sold separately.
Can I use slats from another manufacturer?
Only if their dimensions and attachment requirements are compatible with the 0.827″ channel opening and the Alumission fastening system. Confirm compatibility before ordering or modifying the profile.
Can wood or composite boards be inserted into the channels?
They may fit if their actual dimensions are compatible, but wood and composite materials expand and contract differently from aluminum. Clearance, drainage, fasteners, weight, and span requirements must be evaluated before installation.
Finish & Maintenance
What colors are available?
The profile is available in Black, Bronze, White, Dark Gray, and Light Gray.
Is the profile powder coated?
Yes. The profile receives a durable powder-coated finish designed for outdoor aluminum fence and gate applications.
Will the aluminum post rust?
Aluminum does not develop red rust like untreated steel. The powder coating also provides additional protection and a consistent finished appearance.
Is the profile suitable for outdoor use?
Yes. It is designed for exterior aluminum fence and gate installations.
How should the powder-coated finish be cleaned?
Use clean water, mild soap, and a soft cloth or nonabrasive sponge. Avoid steel wool, harsh chemicals, abrasive cleaners, and tools that can scratch the finish.
Will every powder-coated part be exactly the same color?
Yes. Alumission’s mass-production powder-coating process provides highly accurate and consistent colors across matching components.
Is this product fireproof?
Yes. The aluminum profile is fireproof and noncombustible; it does not burn.
Is the profile made in the USA?
Yes. This aluminum profile is made in the USA.
Dimensions & Material
What are the outside dimensions of the profile?
The overall cross-section measures approximately 3.500″ wide × 1.752″ deep.
What is the wall thickness?
The nominal unmarked wall thickness is approximately 0.057″. All dimensions are nominal, and standard aluminum-extrusion tolerances apply.
How wide is each slat channel opening?
The clear opening of each main slat channel is approximately 0.827″.
How far do the slats insert into the channel?
The approximate slat insertion depth is 1″.
What is the size of the center cavity?
The center cavity measures approximately 1.299″ × 1.299″. It is sized to accept a 1-1/4″ steel tube for a post base or profile extension while providing the necessary installation tolerance.
What aluminum alloy is used?
The profile is manufactured from 6063-T6 aluminum, an architectural aluminum alloy commonly used for extruded fence, gate, and building components.
Is the profile solid or hollow?
It is a hollow, multi-chamber aluminum extrusion. This construction provides useful strength while keeping the profile lighter than a comparable solid section.
How much does the profile weigh?
The profile weighs approximately 1.083 pounds per linear foot. Actual weight may vary slightly because of extrusion tolerances and the applied finish.
What lengths are available?
The 6-foot and 8-foot profiles are available for online purchase. The 10-foot and 20-foot profiles must be ordered by phone with an Alumission representative, cannot be purchased online, and additional shipping charges may apply.
Are the listed dimensions exact?
The dimensions are nominal. Minor dimensional variations are normal with extruded aluminum and powder-coated finishes.
Installation
How deep should the post be embedded in concrete?
The required embedment depends on fence height, post spacing, soil conditions, wind exposure, local codes, and the overall system design. Verify the appropriate footing and embedment requirements for your project before installation.
What size concrete footing is required?
There is no single footing size suitable for every installation. Footing diameter and depth must be selected according to soil conditions, fence height, wind load, post spacing, and applicable building requirements.
Does the inside of the post need to be filled with concrete?
Mainly, no. The concrete footing normally surrounds the embedded portion of the post. Internal filling or additional reinforcement is only needed when required by the specific project design.
What post spacing should I use?
Typical post spacing is 6 to 8 feet on center. Final spacing depends on the slat length, fence height, wind exposure, soil conditions, installation type, and applicable building requirements.
Can the profile be cut to a shorter length?
Yes. It can be field-cut using suitable aluminum-cutting equipment and a blade intended for nonferrous metal. Measure carefully and protect the powder-coated finish while cutting.
Will a cut edge rust?
No. Aluminum does not rust like steel.
Can I drill additional holes into the profile?
Yes, when required for the approved fence or gate assembly. Drilling or modifying the profile should be carefully planned because modified products cannot be returned.
Can this aluminum profile be welded?
6063-T6 aluminum can be welded by a qualified aluminum fabricator, but welding can damage the powder coating and affect the heat-treated properties around the weld. Welding should only be performed as part of a properly designed assembly.
Ordering, Shipping & Returns
What is included with my order?
Each quantity includes one Aluminum Post – 2 Channels in the length and powder-coated color selected before adding it to the cart.
Does the price change with the length?
Yes. Select both the required length and color to display the exact price for that variation.
Is the 20-foot profile supplied as one continuous piece?
Yes. The 20-foot option is supplied as one continuous profile and must be ordered by phone with an Alumission representative. Shipping charges and delivery-access requirements may apply.
Does this product qualify for free shipping?
The 6-foot and 8-foot profiles purchased online qualify for Alumission’s current free-shipping offer. The 10-foot and 20-foot profiles are ordered by phone, and additional shipping charges may apply.
Can I return the post after cutting or drilling it?
No. Cut, drilled, installed, altered, or otherwise modified profiles are not eligible for return.
What is the return period for an unmodified post?
Eligible products may be returned within 30 days of delivery when they are unused, uninstalled, undamaged, and in their original condition. The customer is responsible for normal return-shipping costs.
What should I do if the profile arrives damaged?
Photograph the packaging and damaged product and contact Alumission promptly. Damaged or defective products are handled through Alumission’s replacement and return process.
