Pedestrian Gate
Aluminum Single Swing Gate Kit – Dallas Style
5
(1)
Reviews
All hardware included (self closing hinges, keyed lever, screw ect.) Any deadbolt or smart lock can be installed.
STARTING AT $1,430.00
WHAT’S INCLUDED:
Alumission Dallas Style Gate Kit
Elevate your home’s curb appeal with our sleek and modern Los Angeles Style Gate Kit. This DIY kit is designed to provide a clean, minimalist look that complements any architectural style.
Key Features:
Durable Aluminum Construction: Built to last, our gates are made from high-quality aluminum, ensuring long-lasting performance.
Customizable Design: Tailor the gate to your specific needs with various customization options, including size, color, and hardware.
Easy Installation: Our straightforward installation process makes it easy to assemble your gate without professional help.
Sleek, Modern Aesthetic: The clean lines and minimalist design of the Los Angeles style create a timeless look.
Enhanced Security: Protect your property with a sturdy and secure gate that deters intruders.
What’s in the box?
x2 Gate frame 6′ (5″x1.75″x72″)
x4 Gate frame caps for top and bottom (5″x1.75″x.07″)
x2 Gate frame cover 6′ (.7″x.2″x72″)
x2 Side post 6′ (1.75″x1.875×72″)
x4 Side post cap for top and bottom (1.875″x1.75″x.07″)
x2 Post cover 6′ (.24″x1″x72″)
x1 Gate frame stopper 6′
x1 Side post stopper 6′
x2 Black stainless steel hinges including stainless steel screws
x1 Black self-closing hinge including stainless steel screws
x100 #8 .5″ self-drilling flat head stainless steel screws
x1 Schlage keyed lever- black
x50 1/2″ aluminum spacers
Aluminum slats (5.5″x.8″ and 1″x.8″) ** Quantity and length depend on the gate kit size.
Notes:
* The gate comes as parts and should be built to size.
** The width size chosen should be the size of the total opening. The kit will fit max opening including the side posts.
*** Slats will be 12″ shorter than the opening. Together with two side posts and the gate frame it will add 12″ to the slats size covering the opening needed.
Box Size:
13″W x 7″H x 79″L or 13″W x 11″H x 75″L
Weight 71-110lb (depends on the gate size)
Shipping Details:
Delivery in all US states (Excluded Hawaii)
Black: Ships within 3-8 business days
Special Colors & Wood Grain Finishes: Ships within 4-8 weeks
Box Weight
Weight 78lb-83lb
Box Dimension
13″W x 7″H x 79″L
TECHNICAL SPECIFICATIONS & INSTALLATION
The gate’s frame thickness is 1-3/4″ and any standard lock, lever or deadbolt can be installed on it. The gate can be built to fit a maximum opening of 47.5″ width (including the side posts) and maximum height of 72″.
What’s in the gate kit?
* x2 Gate Frame 6′ (5″x1.75″x72″) including top and bottom caps for each post (5″x1.75″x.07″)
* x4 Gate frame cover 6′ (.7″x.2″x72″)
* x2 Side post 6′ (1.75″x1.875×72″) including top and bottom caps for each post (1.875″x1.75″x.07″)
* x1 Post Cover 6′ (.24″x1″x72″)
* x1 Gate Stopper 6′ x2 Black Stainless Steel Hinges (can be used as regular or self closing), including x20 #10 1.5″ self-drilling flat head stainless steel screws
* x100 #8 .5″ self-drilling flat head stainless steel screws
* x1 Kwikset Daylon Keyed Lever
For The Different Styles:
- Los Angeles Style: x6 1×6 aluminum slats (5.5″x.8″x72″) and x25 1/2″ aluminum spacers
- Las Vegas Style: x3 1×6 aluminum slats (5.5″x.8″x72″), x10 1×1 aluminum slats (1″x.8″x72″) and x55 1/2″ aluminum spacers
- New York Style: x7 1×6 aluminum slats (5.5″x.8″x72″)
- San Francisco Style: x24 1×1 aluminum slats (1″x.8″x72″) and x100 1/2″ aluminum spacers
- Miami or Dallas Style: x5 1×6 aluminum slats (5.5″x.8″x72″), x6 1×1 aluminum slats (1″x.8″x72″) and x50 1/2″ aluminum spacers
Box Size:
13″W x 7″H x 79″L
Weight 78lb-83lb
Shipping Details:
3-8 Business Days delivery in all US states.
Gate Kit Assembly & Installation Guide
Follow the four illustrated pages in order before cutting or assembling the gate. Important: In Part B, Stage 4, cut the slats 8″ shorter than the opening between the installed side posts. Click any page to view it at full size.
Questions & Answers
Find clear answers about Wall Topper sizing, 6-foot spans, included components, base-plate installation, concealed fasteners, style differences, finishes, maintenance and field fitting.
Sizing & Planning
What span is the aluminum Wall Topper designed for?
Each Wall Topper section is designed around a nominal 6-foot span between posts. The supplied horizontal slats are 6 feet long. Verify the actual field measurement before cutting, and plan one post per span plus one terminal post at the end of the run.
Which Wall Topper heights are available?
All five Wall Topper styles are offered in seven nominal heights: 1 foot, 1 foot 6 inches, 2 feet, 2 feet 6 inches, 3 feet, 3 feet 6 inches, and 4 feet. Select the height that fits the project, then review the exact style-specific material schedule shown on the product page.
How do I plan a multi-span Wall Topper run?
Divide the finished run into nominal 6-foot sections. Use one post for each span and add one terminal post at the end of the run. Confirm corners, end conditions, wall steps, field cuts, post locations, and local requirements before ordering.
How do I measure an existing wall for a Wall Topper?
Measure the total finished run, each individual wall section, corners, steps, end conditions, and the usable mounting surface. Mark proposed post locations and check for caps, slopes, drains, utilities, or other obstructions. Use actual field measurements—not only nominal wall dimensions—before ordering or cutting.
Can the 6-foot Wall Topper slats be cut for a shorter span?
Yes. The aluminum slats are supplied in 6-foot lengths and may be field cut to fit a shorter verified opening. Use suitable cutting equipment, keep cuts square, remove burrs, protect the finish, and confirm the finished post-to-post dimension before cutting.
Kit Contents & Style Options
What is included with an Alumission Wall Topper kit?
The selected kit includes Aluminum Post 2 Channels, two channel covers and one cap per post, an 18-inch zinc-coated steel post base and matching aluminum base cover per post, 6-foot aluminum slats in the selected style and height, the required pattern spacers where applicable, and stainless steel self-drilling assembly screws. Wall anchors are not included because the correct fastener depends on the wall material and project conditions.
How do Dallas, Los Angeles, Miami, New York, and San Francisco styles differ?
Dallas combines wide 5.5-inch slats with a four-slat 1-inch accent band. Los Angeles uses evenly spaced 5.5-inch slats. Miami centers a four-slat 1-inch accent band between wide slats. New York is a tight-stacked full-privacy design with size-specific finishing slats. San Francisco uses closely spaced 1-inch slats for a linear look. See the exact material schedule and proportional drawings on each style page.
Is the Wood finish real wood?
No. The Wood option is a wood-look finish applied to aluminum slats, not natural timber. It provides the warmth of a wood appearance while keeping the low-maintenance, noncombustible aluminum construction of the Wall Topper system.
How much privacy does an aluminum Wall Topper add?
Privacy depends on the selected style, height, slat sizes, and spacing. New York is the most closed design, while Dallas, Los Angeles, Miami, and San Francisco create different levels of screening and visibility. Compare the style-specific drawings and material schedule before choosing.
Installation & Mounting
How do the base plate and base cover work?
Each post uses a zinc-coated steel base with a 4-inch by 4-inch plate and an 18-inch stem. The plate is anchored to a structurally suitable wall, the aluminum base cover slides over the plate to conceal the mounting screws or anchors, and the aluminum post slides over the steel stem. Plumb and align every post before installing the slats.
Can the Wall Topper be installed on concrete, masonry, wood, or steel?
Installation may be possible on concrete, masonry, properly reinforced wood, steel, or another structurally suitable wall when the correct substrate-specific anchors are used. Anchors are not included. The installer is responsible for confirming wall condition, edge distances, waterproofing, fastener selection, wind exposure, loads, and code or permit requirements.
Are anchors for the existing wall included?
No. Wall anchors are not included because the correct fastener and embedment depend on the wall material, wall condition, edge distances, loads, and site exposure. Select an anchor system specifically approved for the actual substrate and project conditions.
How do I know whether my wall can support a Wall Topper?
The existing wall and its foundation must be structurally suitable for the planned topper, anchors, height, and site loads. Inspect the wall for cracks, loose caps, deterioration, insufficient thickness, or other damage. When suitability is uncertain, have a qualified contractor or design professional evaluate it before installation.
Care, Ordering & Support
Does the Wall Topper require welding?
No welding is required for the kit assembly. Installation is a mechanical field-fit process that requires accurate measuring, cutting, drilling, leveling, fastening, and anchoring. Channel covers snap into place after assembly to conceal the slat-fastening screws.
Which finishes are available, and how should the Wall Topper be maintained?
Current finish options may include Black, Bronze, White, Dark Grey, Light Gray, and Wood. Availability can change by configuration. Clean powder-coated aluminum with water, mild soap, and a soft cloth; avoid abrasive pads, harsh chemicals, and tools that can scratch the finish.
What should I verify before ordering?
Confirm the total run length, selected style and height, number of 6-foot spans, post and terminal locations, corners or steps, wall construction, anchor plan, finish, field-cut requirements, access, wind exposure, and local rules. Product drawings support selection and installation planning but are not stamped structural or permit drawings.
Can a Wall Topper follow a stepped or sloped wall?
A stepped wall can often be planned as separate level sections with post locations and field cuts coordinated at each change in elevation. A continuously sloped wall requires a custom layout. Measure every section carefully and confirm the proposed arrangement with Alumission before ordering.
Do I need a permit or HOA approval for a Wall Topper?
Requirements vary by location and property. Check local height limits, setbacks, wind and structural rules, permit requirements, easements, and any HOA or architectural-review standards before ordering or installing. The product drawings are planning references, not stamped permit or structural drawings.
